ProductName: ConcreteSquarePileWireCageWeldingMachineSize:1.5×20×2.2mMaterial:steel Features: 1.Ourmachineusethemachineandmaninterface,thecagelength,pitch,closewindingcanberesetintotheMicro-computer.Easytolearnandoperate. 2.Themainmachineusetheoilimmersedgearwheeldrivingsystem. 3.AdoptthehighACweldingtechnology,maketheelectriccircuitsimple,lowfailurerate,andweldingspotismoresolid,alsosaveelectricity. 4.Variablefrequencyspeedcontrolsystem,longerusinglife. 5.SteelSpiralwirerollingtray,morefastandconvenient. ProductsDescription: ConcreteSquarePileWireCageWeldingMachineisaspecial-purposewelderusedtoproducethehigh-strengthconcretepipepilereinforcementcages.Thewelderiswidelyappliedtoreinforcementcageweldingbyself-stressingandpre-stressingmethodandpost-tensioningmethod. Technicalparameters: Edge of square cage250,300,350,400,450,500,600mmLength of welded reinforcement cage4M-15MNumber of longitudinal reinforcements4,8,12,etcDiameter of longitudinal reinforcementø7.1, ø9.0, ø10.7, ø12.6MMDiameter of hoop reinforcementø4- ø6Driving power8.4KW-15.2KWWelding power200KVA-300KVAControllerCNC controller

Concrete Square Pile Wire Cage Welding Machine

Category:

Square Pile Cage Welding Machine

Keyword:

Tel:

+86-523-86608111

Send Inquiry

隐藏域元素占位

Product Detail
Information
contact us

Square concrete pile steel bar cage welding machine is a special-purpose welder used to produce the
high-strength concrete pipe pile reinforcement cages. The welder is widely appliedto reinforcement cage
welding by self-stressing and prestressing pretensioning method and post-tensioning method.
Taizhou amity care international co.,ltd is regarded as the foreign trade department of Taizhou xurui
machinery manufacturing co;, all abroad (overseas) tasks and international businesswill be undertaken
by "amity care ".We are manufacturers of centrifugal spinning machine ,mould ,heading machine ,cutting
machine,cage welding machine , tension jack for pre-stress .feeding machine for different capacity ,weave
welding machine ,sheet cutting machine etc. we also can supply setting up a new factory full line service .
We have already exported various kinds of concrete pile , pole and pipe concern making machines to
overseas countries and regions such as indonesia,parkistan,Vietnam ,myanmar ,korea,malaysia ,south
african etc .Mideast, Southeastern Asia.

Product Name:

Concrete Square Pile Wire Cage Welding Machine

Size: 1.5×20×2.2m

Material: steel

Features:

1. Our machine use the machine and man interface, the cage length, pitch, close winding can be reset into the Micro-computer. Easy to learn and operate.

2. The main machine use the oil immersed gear wheel driving system.

3. Adopt the high AC welding technology, make the electric circuit simple, low failure rate, and welding spot is more solid, also save electricity.

4. Variable frequency speed control system, longer using life.

5. Steel Spiral wire rolling tray, more fast and convenient.

Technical parameters:

Diameter of welded frame	ø110-ø250( as users require)
Length of welded reinforcement cage	4M-15M
Number of longitudinal reinforcements	6, 7, 10 , 12, 14, etc
Diameter of hoop reinforcement	ø7.1, ø9.0, ø10.7, ø12.6MM
Cage pitch	0-100mm
Driving power	8.4KW-15.2KW
Welding power	200KVA-300KVA
Diameter of hoop reinforcement	ø4- ø6
Controller	NC controller
